SHINYEI濕度傳感器CL-M53R
Application range
This specification is applied to the Humidity Sensor Type CL-M53R.
2. Configuration
The configuration of this Humidity Sensor is shown in the drawing of page 3/4 in Fig.1.
3. Electrical characteristics
(3- 1)Rated voltage: 1Vrms (MAX)
(3- 2)Rated power: 0.2mA(MAX)
(3- 3)Operating Frequency range: 500Hz～2kHz
(3- 4)Operating Temperature range: 0～60℃
(3- 5)Operating Humidity range: 90%rh or less
(3- 6)Humidity-Resistance and Humidity Accuracy
at 25℃,1kHz,1VAC(SINE WAVE)
HUMIDITY(%rh) 60
Nominal Value(ｋΩ) 31.0
Range(ｋΩ) 19.8 ～ 50.2
Accuracy(%rh) ±5
Standard measuring condition
25℃, Frequency: 1kHz, Voltage: 1vrms (sine wave)
Leave the sensor in dry air at 25℃, 0%rh for 30 minutes, then leave it at 60%rh
and measure its resistance after 15 minutes. |
